Chipset |
AMD B450 |
CPU SUPPORT |
Supports AMD AM4 Socket for 3rd, 2nd and 1st Gen Ryzen/2nd and 1st Gen Ryzen with Radeon Vega
Graphics/Athlon with Radeon Vega Graphics Processors |
MEMORY |
Support Dual Channel DDR4 1866/2133/2400/2666/2933/3200(OC) MHz
Max. Supports up to 64GB Memory
Each DIMM supports non-ECC 8/16 GB DDR4 module |
INTEGRATED VIDEO |
By CPU model
Supports DX12
Supports HDCP |
STORAGE |
6 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10
1 x M.2 (M Key) 32Gb/s Connector: Support PCI-E (32Gb/s) & SATA III (6Gb/s) SSD
* M.2 (32Gb/s) : The bandwidth is depended on CPU, Ryzen is 32Gb/s ; APU & CPU is 16Gb/s.
* When PCIE-M2_1 slot is occupied, the SATAIII_1 / SATAIII_2 connector will be disabled. |
LAN |
Realtek RTL8118AS – 10/100/1000Mb/s Controller |
AUDIO CODEC |
Realtek ALC1150 7.1-Channel Audio
Support HD Audio
Support SPDIF_out |
USB |
1 x USB 3.2 Gen2 Type-C Port(10Gb/s) (1 on rear I/O)
1 x USB 3.2 Gen2 Type-A Port(10Gb/s) (1 on rear I/O)
4 x USB 3.2 Gen1 Ports (5Gb/s) (2 on rear I/Os and 2 via internal headers)
6 x USB 2.0 Ports (2 on rear I/Os and 4 via internal headers) |
EXPANSION SLOT |
1 x PCI-E 3.0 x16 Slot
1 x PCI-E 2.0 x16 Slot(x4)
2 x PCI-E 2.0 x1 Slots |
REAR I/O |
1 x PS/2 Keyboard/Mouse
1 x USB 3.2 Gen2 (10Gb/s) Type-C Port
1 x USB 3.2 Gen2 (10Gb/s) Type-A Port
2 x USB 3.2 Gen1 (5Gb/s) Ports
2 x USB 2.0 Ports
1 x HDMI Connector ,resolution up to 4096 x 2160@30Hz
1 x DVI-D Connector ,resolution up to 1920 x 1200 @60Hz
1 x VGA Port ,resolution up to 1920 x 1200 @60Hz
1 x LAN Port
6 x Audio Jacks |
INTERNAL I/O |
1 x USB 3.2 Gen1 Header(5Gb/s) (each header supports 2 USB 3.2 Gen1 ports)
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
6 x SATA III Connector (6Gb/s)
1 x Front Audio Header
1 x Front Panel Header
1 x S/PDIF-Out Header
1 x CPU Fan Connector
2 x System Fan Connector
2 x 5050 LED Header
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x Clear CMOS Header
1 x COM Port Header |
H/W MONITORING |
CPU / System Temperature Monitoring
System Fan Monitoring
Smart / Manual CPU Fan Control |
DIMENSION |
Micro ATX Form Factor Dimension: 24.4cm x 24.4cm ( W x L ) |
OS SUPPORT |
Supports Windows 10(64bit) / 11(64bit)
Windows 7(64bit) for Bristol Ridge/ Summit Ridge/ Pinnacle Ridge only
※Biostar reserves the right to add or remove support for any OS with or without notice. |
BUNDLE SOFTWARE |
Racing GT EVO Utility
FLY.NET
BullGuard
BIO-Remote2
Smart Speed LAN |
ACCESSORIES |
4 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual |
FEATURES |
VIVID LED DJ
5050 LED FUN ZONE
Dual BIOS
BIO-FLASHER
Iron Slot Protection |
Caution!! The specification and pictures are subject to change without notice! |
